Bộ Lưu Điện UPS CyberPower PR2200ELCDSL Line-Interactive 2200VA/1980W
Chi tiết UPS CyberPower PR2200ELCDSL Line-Interactive 2200VA/1980W
| CyberPower Professional Tower Series PR2200ELCDSL – UPS – 1980 Watt – 2200 VA | |
|---|---|
| Device Type | UPS – external |
| Weight | 23.3 kg |
| Input Voltage | AC 230 V |
| Output Voltage | AC 230 V ± 10% |
| Power Capacity | 1980 Watt / 2200 VA |
| Input Connectors | 1 x power IEC 60320 C20 16A |
| Output connectors | 8 x power IEC 60320 C13 ¦ 1 x power IEC 60320 C19 |
| Battery | Lead Acid – 9 Ah |
| Batteries Qty | 4 |
| Run Time (Up To) | 3 min at full load |
| Networking | RS-232, USB |
| Dimensions (WxDxH) | 17 cm x 43.2 cm x 22.1 cm |
| Environmental Standards | ENERGY STAR |
| Manufacturer Warranty | 2 years warranty |
Extended Specification
| General | |
|---|---|
| Device Type | UPS – external |
| Battery | |
|---|---|
| Capacity | 9 Ah |
| Quantity | 4 |
| Recharge Time | 8 hours |
| Run Time (Up To) | 3 min at full load ¦ 12 min at half load |
| Technology | Lead Acid |
| Voltage Provided | 12 V |
| Dimensions & Weight | |
|---|---|
| Depth | 43.2 cm |
| Height | 22.1 cm |
| Weight | 23.3 kg |
| Width | 17 cm |
| Environmental Parameters | |
|---|---|
| Humidity Range Operating | 0 – 90% (non-condensing) |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | 0 °C |
| Environmental Standards | |
|---|---|
| ENERGY STAR | Yes |
| Expansion / Connectivity | |
|---|---|
| Interfaces | 1 x management (USB) – 4 pin USB Type B ¦ 1 x management (RS-232) – 9 pin D-Sub (DB-9) ¦ 1 x EPO (emergency power off) |
| Manufacturer Warranty | |
|---|---|
| Service & Support | Limited warranty – 2 years |
| Miscellaneous | |
|---|---|
| Cables Included | EPO cable ¦ Serial cable – external ¦ USB cable – external ¦ Power cable – external – 3 m |
| Compliant Standards | C-Tick, RoHS |
| Equipment Protection Value | 100000 Euros |
| Features | Audible alarm, emergency power off, LCD display, Automatic Voltage Regulation (AVR), GreenPower UPS Technology, overload protection |
| Networking | |
|---|---|
| Remote Management Interface | RS-232, USB |
| Power Device | |
|---|---|
| Frequency Required | 50/60 Hz ± 3% |
| Input Connectors | 1 x power IEC 60320 C20 16A |
| Input Voltage | AC 230 V |
| Input Voltage Margin | ± 3% |
| Input Voltage Range | AC 160 – 283 V |
| Input Voltage Range (Adjustable) | AC 151 – 297 V |
| Output Voltage | AC 230 V ± 10% |
| Output Waveform | Sinewave |
| Power Capacity | 1980 Watt / 2200 VA |
| Power Output Connectors Details | 8 x power IEC 60320 C13 ¦ 1 x power IEC 60320 C19 |
| Surge Energy Rating | 405 Joules |
| Surge Suppression | Yes |
| UPS Technology | Line interactive |
| Software / System Requirements | |
|---|---|
| Software Included | PowerPanel Business Edition |
